IMM40


Product Detail


Product model: IMM40-F/Z

Product name: optical imaging lens set

Product category: variable optical imaging system


  • Achromatic cemented lens, 3 diameters to choose from: Φ64, Φ70 and Φ100 mm

  • Free combination of 2 or 3 lenses, a variety of beam angles, constant angle and linear zoom

  • AR coatings, high resolution and low imaging distortion

  • Super-clear image projection, and highly uniform light spot

  • Suitable for use in LED gobo projector, profile spotlight, follow spotlight, etc

  • Specification:


Product model

IMM40

LED

LES Φ8.5 mm

Condensing lens

IMMDX4450X2 lens set, Φ44, Φ50 and Φ50 mm

Gate

Φ40 mm

Beam angle (constant)

08, 10, 15, 19, 20, 24, 25, 26, 30, 36, 40   (°)

Beam angle (zoom)

08~18, 08~22, 09~27, 11~20, 11~24, 11~33, 12~23, 12~24, 13~25,

13~31, 13~33, 13~34, 15~36, 15~38, 16~27, 16~29, 18~38, 20~39, 20~40   (°)

Model selection

IMM40-F26, a constant angle of 26 degrees

IMM40-Z1536, zoom range from 15 to 36 degrees
