IMM60


Product Detail

Product model: IMM60-F/Z

Product name: optical imaging lens set

Product category: variable optica imaging system



  • Achromatic cemented lens, 3 diameters to choose from: Φ70, Φ100 and Φ140 mm

  • Free combination of 2 or 3 lenses, a variety of beam angles, constant angle and linear zoom

  • AR coatings, high resolution and low imaging distortion

  • Super-clear image projection, and highly uniform light spot

  • Suitable for use in high-power LED gobo projector, profile spotlight, follow spotlight, etc

  • Specification:


Product model

IMM60

LED

LES ≤ Φ22 mm

Condensing lens

IMMDX5070X2 lens set, Φ50, Φ70 and Φ70 mm, for LES ≤ Φ15 mm

IMMDX6672 lens set, Φ66 and Φ72 mm, for LES ≤ Φ22 mm

Gate

≤ Φ60 mm

Beam angle (constant)

09, 10, 14, 15, 19, 20, 24, 25, 26, 30, 36, 40, 45, 50, 55, 60   (°)

Beam angle (zoom)

09~23, 12~26, 12~27, 12~33, 14~41, 16~30, 16~49, 17~34, 17~37,   (°)

18~38, 19~46, 20~49, 22~45, 22~53, 23~57, 24~43, 30~60   (°)

Model selection

IMM60-F26, a constant angle of 26 degrees

IMM60-Z1630, zoom range from 16 to 30 degrees



  • Typical medel light path diagram:
