IMM80


Product Detail


Product model: IMM80-F/Z

Product name: optical imaging lens set

Product category: variable optical imaging system


  • Achromatic cemented lens, 3 diameters to choose from: Φ70, Φ100 and Φ140 mm

  • Free combination of 2 or 3 lenses, a variety of beam angles, constant angle and linear zoom

  • AR coatings, high resolution and low imaging distortion

  • Super-clear image projection, and highly uniform light spot

  • Suitable for use in high-power LED gobo projector, profile spotlight, follow spotlight, etc

  • Specification:

Product modelIMM80
LEDLES Φ28 mm
Condensing lens setIMMDX10073 lens set, Φ73 and Φ100 mm
IMMDX100X273 lens set, Φ73, Φ100 and Φ100 mm
Gate (Gobo content) Φ80 mm
Beam angle (constant)14, 19, 26, 36, 40, 50, 55   (°)
Beam angle (zoom)11~32, 15~30, 16~30, 17~36, 22~40, 28~55, 30~55, 30~60 (°)
Model selectionIMM80-F26, a constant angle of 26°
IMM80-Z1530, zoom range from 15 to 30°


  • Typical model light path diagram:



  • Pattern and spot projection effect:
