Product model: MATLASER

Product name: Laser matrix module

Product category: Optical fly-eye lens matrix module


The MATLASER laser matrix module is composed of two parts as optical lens assembly and laser matrix. There are three models with different powers to choose from, and they have different focal lengths and spot sizes, please refer to the below model selection table.


ModelMATLASER150MATLASER250MATLASER400
Light emission size (mm)Φ48.5Φ70Φ78
G (mm)Φ2Φ3Φ4
Mimimun beam angle (degree)0.450.650.9
Number of laser chips in matrix71319
Luminous flux of the matrix module (lm)7,000 13,00019,000
Power (W)140260380


Light pattern:
